    Disc Rotary 60Hz 2500mm Overylay Hardfacing Machine

    Ask Lasest Price
    Brand Name : JINHUA
    Model Number : JH-DEG360
    Price : USD+2000-50000+Unit
    Payment Terms : T/T
    Supply Ability : 30+Unit+Per Month
    Delivery Time : 15-60 Days
    • Product Details
    • Company Profile

    Disc Rotary 60Hz 2500mm Overylay Hardfacing Machine

    Rotary Overylay Welding Machine, Rotary Cladding System, Rotary Hardfacing Machine


    1. Component

    The JH-360 is composed of a rotary platform, first-stage RV deceleration, second-stage rotary platform and various rotating conductive parts. During the welding, the client shall install his offline welding equipment on JH-360DEG and we will be responsible for the technologies to the control cable interface. The JH-360 can input rotation, load-bearing support and conductive link and work with the offline equipment to form a welding unit for automatic mill overlay welding.


    2. Working Principle

    The specialized JH-360 Refiner Plate Overlay Welding Machine can carry out the off-line overlay welding to refiner plates by a combination with off-line welding equipment, among which JH-DEG360 inputs rotation and rotary conduction, while the off-line equipment works as welding unit.


    3. Composition of Electrical Parts

    The electrical part is mainly controlled through the frequency converter, stepless speed regulation and circulating water cooling power control.


    4. Specification


    Diameter Range of Overlay Welding100mm-6500mm
    Height of Welding Pipes500mm-1500mm
    Diameter of Welding Wireφ1.2-φ2.8mm(Flux-Cored Wire)
    Overlay Welding Thickness of Monolayer2.5-6.5mm
    Rotating Speed0-1500mm/rpm


    5. Delivery
