7000mm Gantry Overlay Cladding Machine For Stainless Steel Tube

    Buy cheap 7000mm Gantry Overlay Cladding Machine For Stainless Steel Tube from wholesalers

    Buy cheap 7000mm Gantry Overlay Cladding Machine For Stainless Steel Tube from wholesalers
    • Buy cheap 7000mm Gantry Overlay Cladding Machine For Stainless Steel Tube from wholesalers

    7000mm Gantry Overlay Cladding Machine For Stainless Steel Tube

    Ask Lasest Price
    Brand Name : JINHUA
    Model Number : JH-210S
    Price : USD+5000-50000+Unit
    Payment Terms : T/T
    Supply Ability : 30+Unit+Per Month
    Delivery Time : 15-60 days
    • Product Details
    • Company Profile

    7000mm Gantry Overlay Cladding Machine For Stainless Steel Tube

    Gantry Type Overlay Cladding Machine


    Product Introduction:


    1. With 1000-7000mm effective lifting stroke and retracting stroke.
    2. Boom end capacity up to 300kg. With 100x100mm cross slides.
    3. Automatic welding for tank/pipe/vesssel straight seam and circle seam.
    4. Seam tracker and Monitor to make sure the welding result better.
    5. Flux recovery machine is also can be optional.
    6. Voltage 220V 380V 480V 600V 50/60Hz are all can be customized
    7. Remote hand control box is also standard configuration
    8. Working with welding rotator and welding positioner etc
    9. Welding source can be Tig/Mig/Saw welding,even plasma welding source
    10. Outside seam welding,inside seam welding & circle seam welding.

    Product characters:


    1. Structure:Fixed ,Fixed with Rotation and Movable with Rotation.
    2. Equipment is cold-blended and go through annealing treatment.
    3. There is anti-failing device to ensure the safety of boom lifting.
    4. Boom retracting adopts VFD,being stable and reliable.
    5. X-Y slide is fixed on one end of boom, controlled by remote panel.
    6. Column rotation controlled by manual operation or electric drive.
    7. Optional: Trolley,seam tracking,monitor system,flux recovery machine etc
    8. Famous spare parts using to ensure good quality and long time using.


    Specification:

    TypeLight DutyMedium DutyHeavy DutySuper Heavy
    The rectangular guiding rail wktth of column and boom(mm)25356075
    Lifting stroke(m)1-32-52-82-13
    Retracting stroke(m)1-3.52-52-84-12
    Liftng speed(mm/min)450600800800
    Min. height under boom(A) mm)300400450600
    Min. distance from cdumn center to the front end of the boom(B) (mm)500100010001000
    Retracting speed{mm/min>100-1500
    Angle (Degree)±180
    Speed(rpm)By manual
    Trolley traveling speeding(mm/min)Traveling by manual200020001000
    Height of trolley(C) (mm)300440440440
    Span of trolley rain(D) (mm)1200150020002500
