    Touch Screen 500A 300mm Hydraulic Cylinder Seam Welding Machine

    Ask Lasest Price
    Brand Name : JINHUA
    Model Number : JHC400
    Price : USD+2000-50000+Unit
    Payment Terms : T/T
    Supply Ability : 30+Unit+Per Month
    Delivery Time : 15-60 Days
    • Product Details
    • Company Profile

    Touch Screen 500A 300mm Hydraulic Cylinder Seam Welding Machine

    Automatic Welding Machine For Hydraulic Cylinder, Automation Seam Welding Machine


    I. Machine Instruction

    This equipment is composed of lathe bed, rotating head, cross member, manual bracket, pneumatic return sliding table, pneumatic tailstock, elevating mechanism of the torch, welding oscillator, adjusting mechanism of the torch, OTC 500A welding power source, water-cooled torch(equipped with cooling water tank) and electrical control system, etc. It has the features of easy-operation and fast.
    1. Adjusting Mechanism of The Torch
    This component is composed of mounting base, two-dimensional adjusting mechanism and electric elevating, etc. The torch can align the weld seam accurately by fine adjusting the X-direction and Y-direction adjusting mechanism manually. It can weld different diameter workpieces by adjusting the Z-direction adjusting mechanism. Welding oscillator is equipped on the adjusting mechanism.
    2. Cross Member
    The cross member is composed of crossbeam, crossbeam supporting seat, linear sliding rail, stepping motor, gear reducer, gear rack transmission, mounting base, connecting plate, drag chain component and detection device, etc.
    3. Return Mechanism
    The return mechanism is composed of air cylinder, base plate, linear sliding rail, sliding plate, detection device, etc.
    4. Elevating Mechanism of The Torch
    The elevating mechanism of the torch is composed of motor, base plate, linear sliding rail, sliding plate, detection device, etc. This component is installed on the sliding plate of the return mechanism and its maximum travel is 300mm.

    II. Main Components List

    No.DescriptionManufacturer
    1PLCMitsubishi
    2Touch ScreenMitsubishi
    3Electrical ElementSchneider / Siemens
    4Pneumatic ElementAirTAC, Taiwan
    5Linear Guide RailHIWIN, Taiwan
    6InverterTaian, Taiwan
    7Main Spindle ReducerTongli, China
    8Stepping MotorMitsubishi
    9Movement ReducerTongli, China
    10Oscillator MotorMitsubishi
    11Welding Power SourceOTC
    12TorchBinzel


    III. Pictures
