    High Chrome Cast Iron 2.5mm HRC65 Wear Plate Hard Facing Wire

    Ask Lasest Price
    Brand Name : JINGHUA
    Model Number : JH-143
    Price : USD+5000-50000+Ton
    Payment Terms : T/T
    Supply Ability : 200+Ton+Per Month
    • Product Details
    • Company Profile

    High Chrome Cast Iron 2.5mm HRC65 Wear Plate Hard Facing Wire

    High Chrome Cast Iron Hard Facing Wire, Wear Plate Welding Wire


    Product description

    This material combined compact needle shape chromic carbide and super hard niobium carbide. Because it's shape so niobium carbide able to stable the anti grind pile up layer. They working as clamps, maintain the force which structure anti shock force together. At the same time, their super high hardness improved anti grind performance. In JH-143, the chromic carbide and niobium carbide mutually assist and work together, can provide perfect anti grind and anti shock protection performance material.

    Applied in the workpiece which under the highest temperature at 350°C. The assembly not only been seriously wear and will be seriously impacted, example hopper, the high grade wear material will fallen in it and sliding. The motion parts running in the high wear agent and high speed impact the solid, example the roller lining of crusher and high pressure fine press roller.
    The assembly used to shock elements or the relative main body, for example, the hammer and stirring bar in the crusher which machining the hard materials.This welding alloy also can be used as double metal combine anti grind plate, adopt special metal arc welding technology (JH-143) produceing.


    Applications

    ●Sliding Metal Parts
    ●Ripper Teeth
    ●Kiln Trunnions
    ●Facing of Agricultural Points and Equipment
    ●Dragline Chaines
    ●Dozer Blades


    Specification

    Product NameHardfacing Wire
    Welding ProcessOpen Arc
    HardnessHRC58-62
    Diameter& PackageΦ1.6mm &15kg/Spool, Φ2.8mm&250kg/Drum
    Crack ReliefNormal
    Parent MaterialLow And Medium Carbon Steel
    MachinabilityGrinding Only
    Deposit Metal PropertiesAbrasion Wear Resistance
    Welding ThicknessLimit To 60mm
    WeldabilitySmall Spatter, Superior Resistance To Welding Pores.
    ApplicationWelding Coal Mill Roller, Wear Plates, Sugarmill Crusher
    OEMAvailable

    Type of Hardfacing Wire

    ModelWelding TypeProtection GasMelting ElementHardness (HRC)CharacteristicsApplication
    JH-145Burning arcSelf protectionC,Mn,Si,Cr,Mo,Nb,W,V58-62The metallographic organism of weld metal has more combine carbide than DB-143(or DB-CNO), anti high temperature wear consume reach up to 800℃. It has withstand low stress high wear consume and anti corrosive performance.Rolling press machine hard surface layer and decorative pattern layer, raw material grinding
    JH-902WGBurning arcSelf protectionC,Mn,Si,Cr,Mo,Nb,V57-61Chrome carbide,niobium carbide, vanadium carbide, molybdenum carbide and other carbides evenly distribute in strong tough base materia, the melt metal able to anti high temperature (650℃) wear consume, and has withstand middle and low stress high wear consume and anti corrosive performance.Rolling press machine hard surface layer and decorative pattern layer, raw material grinding
    JH-CN-OBurning arcSelf protectionC,Mn,Si,Cr,Nb,V59-63Chrome carbide,niobium carbide, vanadium carbide, and other carbides evenly distribute in strong tough base materia, the melt metal able to anti high temperature (650℃) wear consume, and has withstand low stress high wear consume and anti corrosive performance.Pawl type crusher, screening, harrow device, heat slag shaft pipe, raw material grinding, slag grinding, rolling press machine hard surface layer and anti grind decorative pattern layer, anti wear plate, mud delivery pipe and digger, etc
    JH-KINGBurning arcSelf protectionC,Mn,Si,Cr,Nb,V63-67Except chrome carbide in the weld metal, still contain large quantity thin niobium carbide and vanadium carbide, combine carbide content exceed 40%, super high hardness sand rock has super best wear consume performance. Has withstand low stress high wear consume and anti corrosive performance.Slag grinding, quartz grinding, nickle slag grinding, rolling press machine anti grind pattern.
    JH-KZ1Burning arcSelf protectionC,Mn,Si,Cr,Mo,V60-64Chrome carbide,niobium carbide, vanadium carbide, and other combine carbides evenly distribute in strong tough base material, achieved high anti grind performance. Melt spread metal has stress release cracks.Slag grinding, coal grinding roller in more higher content coal gangue, pile up machine and fan blade

    Pictures







    Quality High Chrome Cast Iron 2.5mm HRC65 Wear Plate Hard Facing Wire for sale
